Hypex FA252 FusionAmp Plate Amplifier

Hypex
SKU:
H05U003264
Availability:
Sent within 4 days! Delivery times: US and UK 2-4, EU 2-6, worldwide 3-8 working days.
€544,00
(No reviews yet) Write a Review
Current Stock:

The price includes VAT within the EU!
Buying from outside the EU? Then get 10% discount on all Hypex products! Use the coupon HYPEX10OFF at checkout and if you have requested delivery outside the EU, you will receive a 10% discount on all Hypex products!
For delivery outside the EU, import taxes and duties will have to be paid by the buyer!

Product information "FusionAmp FA252"
This FusionAmp can be the basis of e.g. a powerful active subwoofer or a two-way monitor. The FA252 has two 250 Wrms Ncore® amplifiers which can also be bridged to form one powerful 500 Wrms amplifier. With the built-in DSP, you enjoy complete freedom to create all the parameters of your active crossover yourself.

Connections
Analogue balanced XLR in and through
Analogue unbalanced RCA input
Digital AES in and through
Digital S/PDIF in and through
Digital Optical TosLink input
USB 2.0 configuration interface

Features
15 biquads per amplifier
Three selectable presets for filters
Source selection
Signal detect
Auto shutdown
BTL capable
Clip protect
Thermal protect
Filter protection
FIR filter capable (minimum firmware 5.7 required)

What is included in the box
The FA252
A printed copy of the user guide
Speaker connection cables

Specifications:
Power (4Ω): 2 x 250W
Power (8Ω): 2 x 150W
Channels: 1 channel / 2 way
Technology: NCORE®
Family: Fusion Amp Family
Mains voltage input: 100-120Vac / 200-240Vac ±10%

Getting Started
We understand you want to experience the sound of your new FusionAmp powered speaker as quickly as possible. Therefore, we have made you this ‘roadmap to success’.

Selecting your Fusion Amps: Before you order your FusionAmps, you have to select the correct version that fits your design. Take a look at the example applications in the product manual and write down your requirements.

Ordering your Fusion Amps: Once you know which FusionAmps you need, you can order them from our online store. Cables to connect to your woofers and tweeters are included. Other cables are not included. If you do not have mains cables or a mini USB cable, you can also add those to your order.

Designing and loading a filter: Since the FusionAmp’s DSP does not contain a filter by default, you need to get started with HFD (Hypex Filter Design). This free software can be downloaded from our website. You can start getting acquainted with the software, even without a Hypex product connected. An elaborate guide on how to design the filters can be found in the product manual.

Installing the FusionAmp in your cabinet: For best performance, the FusionAmp should be installed in a sealed compartment of your speaker cabinet. The product manual includes basic dimensions for installation. Refer to the chapter ‘Installation’ for instructions. Detailed 3D models and 2D drawings can be found on our website, to assist you in designing the speaker cabinet.

Start listening! Once the filters are uploaded to the FusionAmp and the speaker cabinet is fully assembled, you can start listening and tweaking your sound experience.

OPTIONS:
Fusion OLED Display kit
All models of the Fusion Amplifier Family and the DSP3-213 can be extended with the Fusion OLED Display. The Fusion OLED Display will show you all the relevant information such as volume level, active input and preset and will show you all error messages. All messages are very well readable from your listening position. You can mount this Display from the outside of the speaker cabinet. the Display is already fitted with double adhesive tape for assembly in your speaker cabinet. This Display must be used in master devices if the Hypex remote is to be used (remote not included). Furthermore, this Display can also be added in slave devices, but the IR functionality will be disabled. includes: Fusion OLED Display, 5 pin cable 125cm, Manual

FusionAmp Remote Kit
All modules can be extended with the Fusion IR Receiver Kit. It contains a PCBA with IR receiver and bicolour LED, and the necessary cable (125cm). This kit is required in master devices if the Hypex remote is to be used. This kit can also be added in slave devices, but the IR functionality will be disabled. The green LED acts as on-off indicator, the red LED mirrors the protect indicator. If you have an OLED Display kit, you don't need the IR kit!

Hypex Remote
The Hypex Remote can be used in combination with the Fusion IR Receiver Kit or with OLED Display kit to control volume, source, presets and put the system into standby.

FusionAmp Mounting Screws
The Fusion Amp must be mounted into the speaker cabinet with 8 or 10 screws. This set contains 10 selftapping, black, Phillips head screws, 4.3x25.4 mm.

USB 2.0 Cable
With this USB cable you can connect the FusionAmp series plate amplifier to your PC. You can only use it to configure FusionAmp and DSP (HFD). Specifications:USB A - Mini-USB B Length: 1.8 m

Power cord
Please take a close look at your electricity connection! It might be something you can't find here.
IEC 60320 C13 EU - This is usually used in the EU, but not everywhere!
IEC 60320 C13 USA - Used in: North and Central America, Japan.

Loudspeaker binding post 2 poles clear
You don't need this if you're building the FusionAmp amplifier into the speaker. You can connect it directly to the drivers using the supplied cables. But if you want to build it into a separate box, or if you need speaker connections for some reason, you can order them. One piece includes both poles. Goldplated binding post to connect your loudspeakers with your amplifier chassis. For banana plug, spade plug and bare wire connections. This binding post can be mounted as a set with the black spacer or as two single connectors.

Hypex Sticker
This sticker of Hypex can be used on your case or other product where Hypex products are used. Show others what modules you have used to build your own amplifier. Dimensions 50x20mm.

Downloadable documents and programs
2D_CAD FusionAMP FA252 01xx.zip
3D_CAD FusionAMP FA252 01xx.zip
FA Update Tutorial V0300.pdf
ReleaseNotes.pdf
HFD_Help_R2.0.pdf
DSP3-213 v5.7 firmware.zip
Fusion Manual R4.pdf
HFD 5.0 Setup.zip

Options Downloadable documents
Remote KIT
2D_CAD FusionAMP Remote kit 01xx.zip
3D_CAD FusionAMP Remote kit 01xx.zip
FusionAMP Remote Kit 01xx.PDF
Fusion Manual IR KIT R2.3_A6_210920.pdf

Fusion OLED Display kit
3D CAD_Fusion_OLED_Display 01xx.zip
Manual A5-R02 Fusion OLED Display kit_01xx.pdf

Hypex Remote
Hypex Remote manual R6-A4.pdf

Loudspeaker binding post 2 poles clear
Loudspeaker_bindingspost_2_poles_clear.pdf
Loudspeaker bindingpost V2.pdf
